Standard Water Filter Housings

Pentek Standard Filter Housings

Pentek water filter housings are manufactured of a durable polypropylene or clear FDA-compliant Styrene-Acrylonitrile (SAN). These housings are equipped with 3/4" NPT inlet and outlet ports. They are available in both 10" and 20" lengths and will accommodate a range of 2-1/2" to 2-7/8" diameter sediment water filters or carbon water filter cartridges. The reinforced polypropylene filter housing cap offers an optional pressure-relief button on the inlet side to use when changing water filter cartridges. We offer standard filter housings and parts along with housing caps, sumps, and mounting brackets.

3G Standard Filter Housings

3G water filter housings will accommodate a wide range of 2-1/4" to 3-1/8" diameter cartridges. Integral bracket and mounting boss cap versions available. Buttress threads and uniform walls for easier cartridge change and improved strength. Accepts DOE cartridges or Seal-Safe o-ring designed cartridges.

3G standard filter housing sumps are available in 10", and 20" lengths, clear or opaque colors that are constructed of reinforced polypropylene. O-ring not included.

3G standard filter housing caps are available with mounting bosses, integral bracket, meter mount, and optional pressure relief/bleed valve. NPT threaded connections offered in 3/4".

Neo-Pure Standard Stainless Steel Filter Housings

Neo-Pure water filter housings are constructed out of either 304L or 316L stainless steel, and are an excellent choice for many commercial and industrial applications. Housings are able to be customized with a variety of options in order to best fit your specific application.

Shelco Standard Stainless Steel Housings

Shelco water filter housings are American made and designed for industrial and commercial filter applications.

Standard filter housing caps are available in 3/4" NPT with reinforced polypropylene with an optional pressure relief button.

Standard filter housing sumps are available in 10", and 20" lengths, clear or opaque colors that are constructed of reinforced polypropylene. O-ring not included.

Standard filter housing brackets are available in L-shaped or U-shaped configurations in metal with mounting screws.

Standard filter housing parts include wrenches, o-rings, nipples, and replacement meters.
