Filmtec BW30-4040 Brackish Water 2400 GPD RO Membrane Element

Part Number: BW30-4040

Filmtec BW30-4040 Brackish Water 2400 GPD RO Membrane Element

Part Number: BW30-4040
Regular price $283.50

Product not eligible for free shipping

Request A Quote

Shipping Information

Shipping costs are based on your order’s weight, location, and selected shipping option. We strive to ship orders quickly, with expedited orders (Next Day Air or 2 Day) going out the same business day if placed before 4:30PM EST.

Description

The Dow FILMTEC BW Brackish Water Membranes are specifically designed for light industrial applications with higher than normal silt density. Due to the fiberglass outer wrap, these brackish water (BW) membranes can consistently sustain the higher pressures required in these applications.

Specifications:
  • Up to 2400 gallon per day production
  • Up to 600 SIPG
  • Fits standard 4" housings or pressure vessels
  • FILMTEC BW30-4040 is the industry standard for reliable operation and production of the highest quality water


Filmtec RO membranes are wet packed

Compatible with:
Desal AG-Series Tap Water/Brackish RO Elements1206761
Filmtec Membranes80783

Specifications

    Product Details

    Active Area

    78 sq. ft.

    Average Nacl Rejection

    0.99

    Chlorine Tolerance

    <0.1 ppm

    Cleaning Ph Range

    1-13

    Direction

    Outside - In

    Inlet Pressure

    225 PSI

    Inner/Outer Wraps

    Fiberglass

    Material Of Construction

    Polyamide Thin-Film

    Max Feed Silt Density Index

    5 Silt Density Index

    Max Flow Rate

    16 gpm (3.6 m3/h)

    Max Pressure Drop

    15 PSI Differential

    Max Pressure (Psi)

    600psi

    Max Temp (°F)

    113°F

    Membrane Type

    Spiral Wound

    Permeate Flow Rate

    2,400 gpd (9.1)

    Permeate Tube Diameter

    3/4"

    Ph Range

    2-11

    Cartridge Style

    Drop-in

    Diameter

    3.9"

    Shipping Dimensions

    Shipping Length

    41.5 in.

    Shipping Width

    4.5 in.

    Shipping Height

    4.5 in.

    Product Weight & Dimensions

    Product Length

    40 in.

    Product Weight (lbs)

    7.3

Downloads

Filmtec BW30-4040 Brackish Water 2400 GPD RO Membrane Element Manual
