Viqua D4 Plus Ultraviolet Water System Powered by UVMax 12 gpm

Part Number: 650695-PFK Alt. Part Number: 650695 (120v), 650697 (230v), 660089-R

1 5

Viqua / Trojan

Viqua D4 Plus Ultraviolet Water System Powered by UVMax 12 gpm

Part Number: 650695-PFK Alt. Part Number: 650695 (120v), 650697 (230v), 660089-R

MSRP: $0.00

$1,300.00

Choose:

120 Volt 120 Volt With Sediment Prefilter Kit 230 Volt 230 Volt With Sediment Prefilter Kit

Product variants

Request A Quote

Placing a large bulk order? Contact us for a quote.

Shipping Information

Shipping costs are based on your order’s weight, location, and selected shipping option. We strive to ship orders quickly, with expedited orders (Next Day Air or 2 Day) going out the same business day if placed before 4:30PM EST.

Description

Viqua D4 Plus Ultraviolet Water System is a whole house ultraviolet disinfection water treatment system that offers a 12 gpm water flow rate and deactivates harmful bacteria, virus, and microorganisms. The Viqua D4 Plus compact design, simple installation, and low cost of operation is ideal for small to medium size home. Drink confidently with Viqua D4 Plus for quality and reliability from its high-output ultraviolet water purification system.

Specifications:

Three-Year Warranty High-Output UV Lamp
Universal power input
UV intensity monitor with diagnostic test
Viqua controller with water-resistant case
LED display showing lamp replacement reminder
Indicator lights show the status of each system component
Stainless steel chamber with safety cap and special lamp plug
Lamp timer reset button and mute button to silence audio alarm

NOTE: This system is compatible with the 602805 Trojan Lamp and the 602732 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for D4 Plus includes:

Trojan Lamp (1): 602805
Trojan Quartz Sleeve (1): 602732
Trojan O-Rings (2): 2045

Specifications

Product Details
Ambient Temperature Range	32-122 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure
Frequency Rate	50/60 Hz
Inlet Connection	3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	4
Outlet Connection	3/4" MPT
Power	50 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	4"
Flow Rate	12 GPM 23 GPM 9 GPM
Type	Single UV System
Voltage	120V
Warranty & Certifications
Warranty	3 yr on power supply and electrical compnents, 10 yrs on UV chamber, 1 yr on lamps and sensors
Shipping Dimensions
Shipping Length	22 in.
Shipping Width	11 in.
Shipping Height	10 in.
Product Weight & Dimensions
Product Length	20-1/2"
Product Weight (lbs)	13.6

Product Details
Ambient Temperature Range	32-122 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure
Frequency Rate	50/60 Hz
Inlet Connection	3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	4
Outlet Connection	3/4" MPT
Power	50 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	4"
Flow Rate	12 GPM 23 GPM 9 GPM
Type	Single UV System
Voltage	120V
Warranty & Certifications
Warranty	3 yr on power supply and electrical compnents, 10 yrs on UV chamber, 1 yr on lamps and sensors
Product Weight & Dimensions
Product Length	20-1/2"
Product Weight (lbs)	21.8

Product Details
Ambient Temperature Range	32-122 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure
Frequency Rate	50/60 Hz
Inlet Connection	3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	4
Outlet Connection	3/4" MPT
Power	50 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	4"
Flow Rate	12 GPM 23 GPM 9 GPM
Type	Single UV System
Voltage	120V
Warranty & Certifications
Warranty	3 yr on power supply and electrical compnents, 10 yrs on UV chamber, 1 yr on lamps and sensors
Shipping Dimensions
Shipping Length	28 in.
Shipping Width	6 in.
Shipping Height	6 in.
Product Weight & Dimensions
Product Length	20-1/2"
Product Weight (lbs)	14.35

Product Details
Ambient Temperature Range	32-122 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure
Frequency Rate	50/60 Hz
Inlet Connection	3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	4
Outlet Connection	3/4" MPT
Power	50 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	4"
Flow Rate	12 GPM 23 GPM 9 GPM
Type	Single UV System
Voltage	120V
Warranty & Certifications
Warranty	3 yr on power supply and electrical compnents, 10 yrs on UV chamber, 1 yr on lamps and sensors
Shipping Dimensions
Shipping Length	26.75 in.
Shipping Width	28.75 in.
Shipping Height	10 in.
Product Weight & Dimensions
Product Length	20-1/2"
Product Weight (lbs)	43.2

Downloads

Viqua D4 Plus Ultraviolet Water System Powered by UVMax 12 gpm Manual
