AXEON HF4-2540 850 GPD RO Membrane Element

Name: AXEON HF4-2540 850 GPD RO Membrane Element
Brand: AXEON Water
SKU: 200388
Price: 173.2500 USD
Availability: InStock

Mouse over to view larger image.

AXEON HF4-2540 850 GPD Membrane Element

AXEON HF4-2540 Reverse Osmosis Membranes are one of the industries most reliable and highest performing reverse osmosis elements. The HF4-2540 RO membrane elements are available in all standard commercial sizes, feature a protective ABS shell, and are 100% vacuum integrity tested. The polyamide thin-film used in the AXEON HF4 Series membranes is manufactured by a major US membrane film manufacturer.

Permeate Flow Rate: 850 gallons per day
Membrane Type: Polyamide Thin-Film
Applied Pressure: 100 psi
Dimensions: 2.5" x 40"
Minimum Concentrate Flow Rate: 5:1
Chlorine Tolerance: 0 ppm
Maximum Operating Temperature: 113° F
Applications: Extra Low Energy, Brackish Water
Formerly known as RO UltraTec HF4-2540

AXEON HF4-2540 850 gpd RO Membrane Element Spec Sheet

Also Compatible With:

Desal Membranes	AK2540TF, 1206802, AK2540FF, 1206800
Filmtec Membranes	XLE-2540

Certifications

Dimensions

Length

40 "

Diameter

2.4 "

Production

Applied Pressure

100 psi

Permeate Flow Rate

850 gpd

Average NaCl Rejection

98.5 %

Minimum Concentrate Flow Rate

5:1

Membrane Specifications

Outer Wrap

ABS

Flow Direction

Outside - In

Permeate Tube Diameter

0.75 "

Membrane Types

Spiral Wound

Materials

Polyamide Thin-Film

Operating Conditions

Max Temperature

113 °F

Max Pressure

600 psi

Maximum Pressure Drop

10 psid

pH Range, Continuous Operation

2-11

pH Range, Short Term Cleaning

1-13

Maximum Feed Water Turbidity

1 NTU

Maximum Feed Silt Density Index

5 SDI

Chlorine Tolerance

0 ppm
