The Selecto SMF IC614-2 is designed for high volume beverage systems to reduce chlorine, chloramines, bad tastes and odors, total organic compounds, tannins and trihalomethanes.
Features:
- Dirt Holding Capabilities. The porous carbon filters have 14 times more dirt holding capacity than conventional carbon filters.
- Reduces Contaminants. Removes 99% of water contaminants such as chlorine. Reduces chloramines 30 times that of a conventional carbon block.
- Hollow Carbon Micro-Structure. The structure and treatment of these filters feature ultra high porosity carbon, which provides a consistent dispersion of water flow across the filter resulting in cleaner water and very lower pressure drop.
- Withstands High Pressure. The nylon construction of the IC614-2 filter has the ability to withstand high pressure.
- Less Maintenance. Filter replacements are only necessary once a year due to the filter lasting about 10 times longer than other carbon filters.
- NSF Certified. The SMF IC614-2 is tested and certified against NSF/ANSI 42 & 53 Standards.
Weight & Dimensions
Approx Depth | 9" |
Approx Height (Inches) | 23" |
Approx Width (Inches) | 22" |
Weight (lbs) | 29 |
Details
Application | Fountain Beverage System |
Capacity | 150,000 Gallons |
Chloramine Reduction | 30,000 Gallons @ 7.4 GPM |
Cto Reduction Capacity | 150,000 Gallons @ 14 GPM |
Housing Material | Polypropylene |
Inlet/Outlet Connection | 1/2" FPT |
Max Pressure (Psi) | 125 |
Max Temp (°F) | 100 |
Min Pressure (Psi) | 40 |
Min Temp (°F) | 40 |
Size | 1/2" |
Change Frequency | 150,000 Gallons |
Connection Type | Female (FPT) |
Contaminants Reduced | Chlorine/Taste/Odor, Sediment/Dirt/Rust, Chloramine |
Flow Rate | 14 GPM |
Media Type | Ultra High Porosity Carbon with Micro-Structure |
Origin | USA |
Type | Fountain Beverage Systems |
Warranty & Certifications
Certifications | Meets NSF Standard 42 & 53 |
The Selecto Scientific SMF IC614-2 Cold Beverage Filtration System is one filter that does it all. The first Jumbo sanitary filter on the market, the IC614-2 is ideal for any fountain & multi-use application with up to 1 to 3 carbonators such as coffee, tea, and juice.
The Selecto SMF IC614-2 is designed for high volume beverage systems to reduce chlorine, chloramines, bad tastes and odors, total organic compounds, tannins and trihalomethanes.
Features:
- Dirt Holding Capabilities. The porous carbon filters have 14 times more dirt holding capacity than conventional carbon filters.
- Reduces Contaminants. Removes 99% of water contaminants such as chlorine. Reduces chloramines 30 times that of a conventional carbon block.
- Hollow Carbon Micro-Structure. The structure and treatment of these filters feature ultra high porosity carbon, which provides a consistent dispersion of water flow across the filter resulting in cleaner water and very lower pressure drop.
- Withstands High Pressure. The nylon construction of the IC614-2 filter has the ability to withstand high pressure.
- Less Maintenance. Filter replacements are only necessary once a year due to the filter lasting about 10 times longer than other carbon filters.
- NSF Certified. The SMF IC614-2 is tested and certified against NSF/ANSI 42 & 53 Standards.
Weight & Dimensions
Approx Depth | 9" |
Approx Height (Inches) | 23" |
Approx Width (Inches) | 22" |
Weight (lbs) | 29 |
Details
Application | Fountain Beverage System |
Capacity | 150,000 Gallons |
Chloramine Reduction | 30,000 Gallons @ 7.4 GPM |
Cto Reduction Capacity | 150,000 Gallons @ 14 GPM |
Housing Material | Polypropylene |
Inlet/Outlet Connection | 1/2" FPT |
Max Pressure (Psi) | 125 |
Max Temp (°F) | 100 |
Min Pressure (Psi) | 40 |
Min Temp (°F) | 40 |
Size | 1/2" |
Change Frequency | 150,000 Gallons |
Connection Type | Female (FPT) |
Contaminants Reduced | Chlorine/Taste/Odor, Sediment/Dirt/Rust, Chloramine |
Flow Rate | 14 GPM |
Media Type | Ultra High Porosity Carbon with Micro-Structure |
Origin | USA |
Type | Fountain Beverage Systems |
Warranty & Certifications
Certifications | Meets NSF Standard 42 & 53 |
