Colder Products

Multi-Mount Non-Valved Female Thread Coupling Body - 10-32 UNF Chrome

Part Number: MM181032

In Stock

out of stock

In Stock

$18.95


Multi-Mount couplings provide one easy-to-use coupling for connecting three to five lines at one time. Multi-mounts are available in either acetal or chrome plated brass and are keyed to prevent mismatched connections.

Specifications:
  • Material: Brass
  • Color: Chrome
  • Pressure Range: Vacuum to 250 psi, 17.3 bar
  • Mounting Option: Panel Mount
  • Valve Option: Non-Valved
  • Temperature Range: -40ºF to 180ºF
  • Seal Options: Buna-N
  • Available in Bags of 10 units


Weight & Dimensions

Weight (lbs)

0.05

Details

Series

Multi-Mount, MM

Max Temp (°F)

180

Max Pressure (Psi)

500

Min Temp (°F)

-40

Min Pressure (Psi)

Vacuum

Application

Water

Bag Quantity

10

Body Material

Chrome-Plated Brass

Color / Finish

Chrome

Mounting Options

Panel Mount

Origin

USA

Size

10-32

Spring

316 stainless steel

Valve Type

Non-Valved

External Springs And Pin

Stainless Steel

Thumb Latch

Stainless steel

Inlet/Outlet Connection

10-32 UNF


Multi-Mount





Multi-Mount couplings provide one easy-to-use coupling for connecting three to five lines at one time. Multi-mounts are available in either acetal or chrome plated brass and are keyed to prevent mismatched connections.

Specifications:
  • Material: Brass
  • Color: Chrome
  • Pressure Range: Vacuum to 250 psi, 17.3 bar
  • Mounting Option: Panel Mount
  • Valve Option: Non-Valved
  • Temperature Range: -40ºF to 180ºF
  • Seal Options: Buna-N
  • Available in Bags of 10 units

Weight & Dimensions

Weight (lbs)

0.05

Details

Series

Multi-Mount, MM

Max Temp (°F)

180

Max Pressure (Psi)

500

Min Temp (°F)

-40

Min Pressure (Psi)

Vacuum

Application

Water

Bag Quantity

10

Body Material

Chrome-Plated Brass

Color / Finish

Chrome

Mounting Options

Panel Mount

Origin

USA

Size

10-32

Spring

316 stainless steel

Valve Type

Non-Valved

External Springs And Pin

Stainless Steel

Thumb Latch

Stainless steel

Inlet/Outlet Connection

10-32 UNF

Documentation
Multi-Mount
