The Flow-Max HP Series Filter cartridges are cost effective, disposable, filter elements for a wide range of applications. Flow-Max HP cartridges are constructed of highly efficient pleated polypropylene filter media with extended filter area to provide high flow rates, low pressure drop and increased dirt holding capacity.
Features:
- 100% polypropylene
- Ratings from 0.2 to 50 micron
- FDA listed polypropylene components
- Removal efficiencies to 99.98%
- High surface area
- Long service life & reduced maintenance costs
- Fixed pore construction for reliability
- Change Out at 35 PSI Differential
High purity water, Chemicals, Traps for DI resin, Cosmetics, Electronics, Inks, Pre filtration for RO, Food & beverage, Magnetic tape coatings, Bottled water, Aqueous solutions, Edible oils, Plating solutions, Waste water.
Weight & Dimensions
Approx Length (Inches) | 20" (50.8 cm) |
Details
Cap Material | Polypropylene |
Capacity | 6-12 Months |
Cartridge Style | Drop-In |
Case Quantity | 12 |
End Cap Type | DOE |
Gaskets | Buna-N, EPDM |
Initial Pressure Drop | 3.2 PSI Differential |
Inner/Outer Wraps | Polypropylene |
Media Type | Polypropylene |
Micron Rating (Absolute) | 1 Micron |
Netting | Polypropylene |
O Rings | Silicone |
Operating Pressure Range | MAX 130 PSI |
Operating Temperature Range | MAX 175 Degrees Fahrenheit |
Outer Diameter | 2.5" |
Warranty & Certifications
Certifications | FDA CFR-21 |
