Viqua S2Q-OZ Ozone Water System Powered By Sterilight

Part Number: S2Q-OZ

In Stock

out of stock

In Stock

$309.00


The Viqua S2Q-OZ System is made specifically for hot tub and spa applications. The S2Q-OZ is an air venturi disinfection system that is low maintenance and is easily serviced.

Features:
  • Electronic "ICE" ballasts featuring open loop current control ballast features quick-lock moulded lamp connector, audible alarm & power-on indicator
  • Compact design incorporating 304 stainless steel reactor chambers
  • Uses proprietary lamps for use with ozone systems only
  • Ozone systems are nature's way to protect your water without the addition of harmful chemicals
  • Lamp change is easily accomplished without interrupting the water flow
  • Venturi installation kit is NOT included

Notes:
* For any necessary lamp replacements, the S15ROL UV Lamp is compatible with the S2Q-OZ system.
** 230V systems are shipped with 2-prong continental European (CEE-7/7) 2 pin with ground "Schuko" power cord.


Weight & Dimensions

Approx Length (Inches)

16.5 Inches

Power Supply Dimensions

7.3"x3.2"x2.5"

Details

Body Material

304 Stainless Steel Reactor

Diameter

2.5'' Inches; 2.5"

Features

Audible Lamp Failure; Visual Power On; Lamp Timer

Frequency

50-60 Hz

Inlet/Outlet Size

3/8" quick connect; 3/8" Ports

Number Of Lamps

1

Operating Pressure Range

125 PSI

Type

UVC plus Ozone; Ozone

Voltage

100-240 V; 100-240V

Ozone Disinfection Flow Rate

70 mg ozone @5 SCFH air flow


Viqua





The Viqua S2Q-OZ System is made specifically for hot tub and spa applications. The S2Q-OZ is an air venturi disinfection system that is low maintenance and is easily serviced.

Features:
  • Electronic "ICE" ballasts featuring open loop current control ballast features quick-lock moulded lamp connector, audible alarm & power-on indicator
  • Compact design incorporating 304 stainless steel reactor chambers
  • Uses proprietary lamps for use with ozone systems only
  • Ozone systems are nature's way to protect your water without the addition of harmful chemicals
  • Lamp change is easily accomplished without interrupting the water flow
  • Venturi installation kit is NOT included

Notes:
* For any necessary lamp replacements, the S15ROL UV Lamp is compatible with the S2Q-OZ system.
** 230V systems are shipped with 2-prong continental European (CEE-7/7) 2 pin with ground "Schuko" power cord.

Weight & Dimensions

Approx Length (Inches)

16.5 Inches

Power Supply Dimensions

7.3"x3.2"x2.5"

Details

Body Material

304 Stainless Steel Reactor

Diameter

2.5'' Inches; 2.5"

Features

Audible Lamp Failure; Visual Power On; Lamp Timer

Frequency

50-60 Hz

Inlet/Outlet Size

3/8" quick connect; 3/8" Ports

Number Of Lamps

1

Operating Pressure Range

125 PSI

Type

UVC plus Ozone; Ozone

Voltage

100-240 V; 100-240V

Ozone Disinfection Flow Rate

70 mg ozone @5 SCFH air flow
