Toray TM720D-400 11000 gpd Brackish Water Membrane 8 x 40
Part Number: TM720D-400
Alt. Part Number: TM720N-400
in stock
only a few left!
out of stock
Expected ship date
Please note: This item is not available for same day shipping.
Use the chat feature or give us a call at 864-284-1801 for
further information.
Please note: This item is not available for same day shipping. Use
the chat feature or give us a call at 864-284-1801 for further
information.
More expected soon
Please note: This item is not available for same day shipping. Use
the chat feature or give us a call at 864-284-1801 for further
information.
Please note: This item is not available for same day shipping. Use the chat feature or give us a call at 864-284-1801 for further information.
Please note: This item is not available for same day shipping. Use the chat feature or give us a call at 864-284-1801 for further information.
Specifications:
- Dimensions: 8" x 40"
- Applied Pressure: 225 psi
- Chlorine Tolerance: 0 ppm
- Membrane Type: Polyamide Composite
- Maximum Operating Temperature: 113° F
- Permeate Flow Rate: 11,000 gallons per day
- Applications: Tap Water, Brackish Water, Well Water, & Surface Water
Compatible with:
| Filmtec Membranes | BW30-400 & BW30-400/34i |
| GE Water | AG8040F-400 |
| Hydranautics Membranes | CPA2 & CPA3 |
| Koch Membrane Systems | 8822HR-400 |
| TriSep Membranes | 8040-ACM2-UWA & 8040-ACM3-TSA |
| Toray Membranes | TM720-400 |
WARNING!
| Product Details | |
|---|---|
Active Area | 400 sq. ft. |
Average Nacl Rejection | 0.99 |
Chlorine Tolerance | <0.1ppm |
Cleaning Ph Range | 1-13 |
Direction | Outside - In |
Feed Spacer Thickness | 34 mil |
Feed Water Concentration | 2,000 mg/l Nacl |
Feed Water Temperature | 77°F |
Inlet Pressure | 225 PSI |
Material Of Construction | Cross-Linked Polyamide |
Max Feed Silt Density Index | 5 Silt Density Index |
Max Pressure Drop | 15 PSI Differential |
Max Pressure (Psi) | 600 psi |
Max Temp (°F) | 113°F |
Membrane Type | Spiral Wound |
Min Flow Rate | 8,900 gpd (33.6m3 /d) |
Minimum Salt Rejection Cl- (%) | 0.9965 |
Permeate Flow Rate | 11,000 gpd (41.6) |
Permeate Tube Diameter | 1-1/8" |
Ph Range | 2-11 |
Recovery Rate | 0.15 |
Sanitation And Sterilization | Hydrogen Peroxide @ 0.2% and 77° F (25°C) Formaldehyde at 0.5 - 3% |
Stabilized Salt Rejection Cl- (%) | 0.998 |
Diameter | 8" |
Origin | USA |
| Shipping Dimensions | |
Shipping Length | 40 in. |
Shipping Width | 8.63 in. |
Shipping Height | 8.81 in. |
| Product Weight & Dimensions | |
Product Height | 8.81 in. |
Product Length | 40 in. |
Product Width | 8.63 in. |
Product Weight (lbs) | 33.04375 |
Specifications:
- Dimensions: 8" x 40"
- Applied Pressure: 225 psi
- Chlorine Tolerance: 0 ppm
- Membrane Type: Polyamide Composite
- Maximum Operating Temperature: 113° F
- Permeate Flow Rate: 11,000 gallons per day
- Applications: Tap Water, Brackish Water, Well Water, & Surface Water
Compatible with:
| Filmtec Membranes | BW30-400 & BW30-400/34i |
| GE Water | AG8040F-400 |
| Hydranautics Membranes | CPA2 & CPA3 |
| Koch Membrane Systems | 8822HR-400 |
| TriSep Membranes | 8040-ACM2-UWA & 8040-ACM3-TSA |
| Toray Membranes | TM720-400 |
WARNING!
| Product Details | |
|---|---|
Active Area | 400 sq. ft. |
Average Nacl Rejection | 0.99 |
Chlorine Tolerance | <0.1ppm |
Cleaning Ph Range | 1-13 |
Direction | Outside - In |
Feed Spacer Thickness | 34 mil |
Feed Water Concentration | 2,000 mg/l Nacl |
Feed Water Temperature | 77°F |
Inlet Pressure | 225 PSI |
Material Of Construction | Cross-Linked Polyamide |
Max Feed Silt Density Index | 5 Silt Density Index |
Max Pressure Drop | 15 PSI Differential |
Max Pressure (Psi) | 600 psi |
Max Temp (°F) | 113°F |
Membrane Type | Spiral Wound |
Min Flow Rate | 8,900 gpd (33.6m3 /d) |
Minimum Salt Rejection Cl- (%) | 0.9965 |
Permeate Flow Rate | 11,000 gpd (41.6) |
Permeate Tube Diameter | 1-1/8" |
Ph Range | 2-11 |
Recovery Rate | 0.15 |
Sanitation And Sterilization | Hydrogen Peroxide @ 0.2% and 77° F (25°C) Formaldehyde at 0.5 - 3% |
Stabilized Salt Rejection Cl- (%) | 0.998 |
Diameter | 8" |
Origin | USA |
| Shipping Dimensions | |
Shipping Length | 40 in. |
Shipping Width | 8.63 in. |
Shipping Height | 8.81 in. |
| Product Weight & Dimensions | |
Product Height | 8.81 in. |
Product Length | 40 in. |
Product Width | 8.63 in. |
Product Weight (lbs) | 33.04375 |
