Stainless Steel Flow Rates:

• Continuous Flow: 80 gallons per minute
• Flow Range: 2 – 160 gallons per minute
• Pulses per Gallon: 1,2,4

* The size of the meter should be based upon continuous flow and gallons per minute as opposed to pipe size.


Specifications:

• Accuracy: ±1.5% max. flow rate when operating between minimum and maximum flow range
• Temperature Range: 35 -122°F (1.7 -50°C), protect the meter from freezing
• Maximum Operating Pressure: 150 psi (10.3 bar)
• Maximum Current: 20mA
• Maximum Voltage: 24VDC or VAC
• Sensor: Reed switch, dry contact type, normally open
• Cable Length: 6 ft (2 m)

Materials of Construction:

• Body: Stainless Steel
• Internal: Engineered thermoplastic
• Magnet: Alnico
