Features:
- Engineered Hi-Performance Nylon
- High chemical resistance
- EPDM O-ring
- FDA Approved material
- NSF Standard 51 & 61 Certified
- Temperature rated up to 200º F
- Suitable for potable liquids and food applications
Weight & Dimensions
Weight (lbs) | 0.035 |
Details
Series | LIQUIFit |
Max Temp (°F) | 200 |
Max Pressure (Psi) | 230 |
Min Temp (°F) | 35 |
Min Pressure (Psi) | Vacuum |
Push-In Size | 5/16" OD, 8mm OD |
Application | Water, Food, Beverage, Air, Carbonation |
Bag Quantity | 10 |
Body Material | Nylon |
Box Quantity | 100 |
Color / Finish | White |
Mounting Options | Free Floating |
Seal Material | EPDM |
Warranty & Certifications
Certifications | NSF 61, NSF 51, FDA Approved |
Features:
- Engineered Hi-Performance Nylon
- High chemical resistance
- EPDM O-ring
- FDA Approved material
- NSF Standard 51 & 61 Certified
- Temperature rated up to 200º F
- Suitable for potable liquids and food applications
Weight & Dimensions
Weight (lbs) | 0.035 |
Details
Series | LIQUIFit |
Max Temp (°F) | 200 |
Max Pressure (Psi) | 230 |
Min Temp (°F) | 35 |
Min Pressure (Psi) | Vacuum |
Push-In Size | 5/16" OD, 8mm OD |
Application | Water, Food, Beverage, Air, Carbonation |
Bag Quantity | 10 |
Body Material | Nylon |
Box Quantity | 100 |
Color / Finish | White |
Mounting Options | Free Floating |
Seal Material | EPDM |
Warranty & Certifications
Certifications | NSF 61, NSF 51, FDA Approved |
