Parker TrueSeal fittings meet NSF-61 requirements for drinking water system components. The all plastic body designs offer reduced weight, eliminate rust, corrosion and system contamination in applications where metal components cannot be tolerated. TrueSeal fittings are manufactured from FDA compliant materials and are NSF-51 listed for contact with food.
Specifications:
Specifications:
- Patented push-to-connect design
- Assembly without the use of tools
- Connections: 1/2" Barb x 1/2" OD Stem
- Body Construction: Gray Acetal
- Temperature Range: -20°F - 180°F
- Certifications: NSF 51
Details
Application | Water, Air, Beverage, Beer, Wine, Soft Drinks, Dyes |
Barb Size | 1/2" ID |
Body Material | Acetal Copolymer |
Max Pressure (Psi) | 250 |
Max Temp (°F) | 180 |
Min Pressure (Psi) | Vacuum |
Min Temp (°F) | -20 |
Mounting Options | Free Floating |
Series | TrueSeal |
Stem Size | 1/2" OD |
Color / Finish | Gray |
Sub-Type | Stem to Barb Elbow |
Type | Elbow |
Warranty & Certifications
Certifications | NSF 61; NSF 51 |
Parker TrueSeal fittings meet NSF-61 requirements for drinking water system components. The all plastic body designs offer reduced weight, eliminate rust, corrosion and system contamination in applications where metal components cannot be tolerated. TrueSeal fittings are manufactured from FDA compliant materials and are NSF-51 listed for contact with food.
Specifications:
- Patented push-to-connect design
- Assembly without the use of tools
- Connections: 1/2" Barb x 1/2" OD Stem
- Body Construction: Gray Acetal
- Temperature Range: -20°F - 180°F
- Certifications: NSF 51
Details
Application | Water, Air, Beverage, Beer, Wine, Soft Drinks, Dyes |
Barb Size | 1/2" ID |
Body Material | Acetal Copolymer |
Max Pressure (Psi) | 250 |
Max Temp (°F) | 180 |
Min Pressure (Psi) | Vacuum |
Min Temp (°F) | -20 |
Mounting Options | Free Floating |
Series | TrueSeal |
Stem Size | 1/2" OD |
Color / Finish | Gray |
Sub-Type | Stem to Barb Elbow |
Type | Elbow |
Warranty & Certifications
Certifications | NSF 61; NSF 51 |
