JACO polypropylene fittings have good chemical resistance and are unaffected by most weak acids and alkalies. Below 175°F they have good resistance to organic solvents. They should not be used with oxidants or strong acids or in continuous sunlight. The polypropylene used in JACO fittings is 20% glass filled for improved stiffness and is NSF listed.
Advantages of JACO fittings over metal compression fittings:
- Good electrical insulating qualities. This eliminates the electrolytic action that corrodes tubing, caused by a dissimilar metal meeting a fitting.
- Low density and softness of plastic gives JACO fittings the ability to absorb mechanical and acoustical vibrations.
- Low resistance to flow due to the smooth internal surface of the fittings.
- Resistance to scale buildup.
Specifications:
- Connections: 1/2" OD tube x 1/2" FPT
- Fitting Material: polypropylene
- Ferrule nut with integral sleeve for use with soft plastic tubing
- Ferrule nut thread size: 3/4-20
- Max Pressure: 50 psi
- Temperature Range: -30° - 215° F
- Color: opaque white
Compatible with:
| Colder Couplings & Fittings | 2402700 |
Weight & Dimensions
Weight (lbs) | 0.05 |
Details
Max Temp (°F) | 225 |
Max Pressure (Psi) | 50 |
Min Temp (°F) | -30 |
Min Pressure (Psi) | 0 |
Push-In Size | 1/2" OD |
Application | Water |
Bag Quantity | 100 |
Body Material | Polypropylene |
Color / Finish | White |
Mounting Options | Thread |
Size | 1/2" |
Inlet/Outlet Connection | 1/2" FPT |
