The 1/4" flow PLC12 Series offers many of the same configuration options as the PLC Series. The polypropylene material adds greater chemical resistance for more demanding applications and the couplings are gamma sterilizable.
Specifications:
- Material: Polypropylene
- Material Finish:Natural
- Color: Almond
- Pressure Range: Vacuum to 120 psi, 8.3 bar
- Mounting Option: Free Floating
- Valve Option: Non-Valved
- Temperature Range: 32ºF to 160ºF
- Seal Options:EPDM
- Valve Spring: 316 Stainless Steel
- Available in Bags of 25 units
Details
Bag Quantity | 25 units |
Body Material | Polypropylene |
Color / Finish | Almond; Natural |
Mounting Options | Free Floating |
Operating Pressure Range | Vacuum to 120 psi, 8.3 bar |
Operating Temperature Range | 32-160 Degrees Fahrenheit |
Seal Material | EPDM |
Spring | 316 Stainless Steel |
Type | Coupler |
Valve Type | Non-Valved |
The 1/4" flow PLC12 Series offers many of the same configuration options as the PLC Series. The polypropylene material adds greater chemical resistance for more demanding applications and the couplings are gamma sterilizable.
Specifications:
- Material: Polypropylene
- Material Finish:Natural
- Color: Almond
- Pressure Range: Vacuum to 120 psi, 8.3 bar
- Mounting Option: Free Floating
- Valve Option: Non-Valved
- Temperature Range: 32ºF to 160ºF
- Seal Options:EPDM
- Valve Spring: 316 Stainless Steel
- Available in Bags of 25 units
Details
Bag Quantity | 25 units |
Body Material | Polypropylene |
Color / Finish | Almond; Natural |
Mounting Options | Free Floating |
Operating Pressure Range | Vacuum to 120 psi, 8.3 bar |
Operating Temperature Range | 32-160 Degrees Fahrenheit |
Seal Material | EPDM |
Spring | 316 Stainless Steel |
Type | Coupler |
Valve Type | Non-Valved |
