Features:
- Acetal copolymer construction
- O-rings are NBR (Buna-N)
- Unique oval collet design
- FDA approved materials
- For water, air, gases, vacuum, & liquids
- NSF Certified 51 & 62
- Fittings may be gray or white based on availability
Details
Application | Water, Air, Food, Beverage |
Body Material | Acetal Copolymer |
Max Pressure (Psi) | 170 |
Max Temp (°F) | 150 |
Min Pressure (Psi) | Vacuum |
Min Temp (°F) | 34 |
Mounting Options | Free Floating |
Push-In Size | 3/8" OD, 1/4" OD |
Seal Material | Buna-N |
Series | Acetal |
Color / Finish | Gray, White |
Sub-Type | Reducer Elbow |
Type | Elbow |
Warranty & Certifications
Certifications | NSF 61; NSF 51; FDA Approved |
Features:
- Acetal copolymer construction
- O-rings are NBR (Buna-N)
- Unique oval collet design
- FDA approved materials
- For water, air, gases, vacuum, & liquids
- NSF Certified 51 & 62
- Fittings may be gray or white based on availability
Details
Application | Water, Air, Food, Beverage |
Body Material | Acetal Copolymer |
Max Pressure (Psi) | 170 |
Max Temp (°F) | 150 |
Min Pressure (Psi) | Vacuum |
Min Temp (°F) | 34 |
Mounting Options | Free Floating |
Push-In Size | 3/8" OD, 1/4" OD |
Seal Material | Buna-N |
Series | Acetal |
Color / Finish | Gray, White |
Sub-Type | Reducer Elbow |
Type | Elbow |
Warranty & Certifications
Certifications | NSF 61; NSF 51; FDA Approved |
