Amtrol

Amtrol Well-X-Trol WX-202 Well Pressure Tank 20 gal

Part Number: WX-202

Alt. Part Number: 144S29, VW-20

In Stock

out of stock

In Stock

$217.99

The Well-X-Trol WX-202 well tank delivers unparalleled performance and longevity, making them the most recognized brand on the market. With its sealed air charge and unique water chamber design, Well-X-Trol is the choice of professionals. WX-202 now comes standard with Tuf-Kote indoor/outdoor coating technology. This coating allows the well water storage tank to withstand the harshest environments, giving you years of worry-free service.

Specifications:
  • Heavy duty butyl diaphragm
  • Stainless steel system connection
  • Stainless steel air stem
  • Virgin polypropylene liner
  • 100% Helium tested
  • Drawdown 20/40 Setting: 8.0 gallons
  • Drawdown 30/50 Setting: 6.8 gallons
  • Drawdown 40/60 Setting: 5.9 gallons
  • 7 year warranty
  • NSF Standard 61 listed




Weight & Dimensions

Height W/ Stand

31-5/8"

Height (inches)

16

Length (inches)

32.88

Weight (lbs)

33

Width (inches)

16

Details

Air Valve Stem Location

Top

Application

Pressure Pump Tank

Diaphragm Materials

Butyl Rubber

Drawdown Volume

8.0 Gallons @ 20/40 Setting, 6.8 Gallons @ 30/50 Setting, 5.9 Gallons @ 40/60 Setting

Inlet/Outlet Connection

1" FPT

Inlet/Outlet Location

Bottom

Material Of Construction

Stainless Steel

Max Pressure (Psi)

150

Max Temp (°F)

200

Size

1"

Tank Pre-Charge

38 PSI

Volume

20 Gallons

Connection Type

Female (FPT)

Diameter

15-3/8"

Origin

USA

Warranty & Certifications

Certifications

NSF Certified to Standard 61

Warranty

7 year


Amtrol

Amtrol




The Well-X-Trol WX-202 well tank delivers unparalleled performance and longevity, making them the most recognized brand on the market. With its sealed air charge and unique water chamber design, Well-X-Trol is the choice of professionals. WX-202 now comes standard with Tuf-Kote indoor/outdoor coating technology. This coating allows the well water storage tank to withstand the harshest environments, giving you years of worry-free service.

Specifications:
  • Heavy duty butyl diaphragm
  • Stainless steel system connection
  • Stainless steel air stem
  • Virgin polypropylene liner
  • 100% Helium tested
  • Drawdown 20/40 Setting: 8.0 gallons
  • Drawdown 30/50 Setting: 6.8 gallons
  • Drawdown 40/60 Setting: 5.9 gallons
  • 7 year warranty
  • NSF Standard 61 listed



Weight & Dimensions

Height W/ Stand

31-5/8"

Height (inches)

16

Length (inches)

32.88

Weight (lbs)

33

Width (inches)

16

Details

Air Valve Stem Location

Top

Application

Pressure Pump Tank

Diaphragm Materials

Butyl Rubber

Drawdown Volume

8.0 Gallons @ 20/40 Setting, 6.8 Gallons @ 30/50 Setting, 5.9 Gallons @ 40/60 Setting

Inlet/Outlet Connection

1" FPT

Inlet/Outlet Location

Bottom

Material Of Construction

Stainless Steel

Max Pressure (Psi)

150

Max Temp (°F)

200

Size

1"

Tank Pre-Charge

38 PSI

Volume

20 Gallons

Connection Type

Female (FPT)

Diameter

15-3/8"

Origin

USA

Warranty & Certifications

Certifications

NSF Certified to Standard 61

Warranty

7 year
