Fresh Water Systems

Water Pressure Gauge 160 PSI, 1/4" MPT, 2.0" Plastic Dial, Center Mount, SS Case

Part Number: 91B20-C4-43B-160P

Alt. Part Number: 202L-204F

In Stock

out of stock

In Stock

$14.99


The 91B20-C4-43B-160P is a center mount pressure gauge that features a black steel case with copper alloy internals. This easy-to-read utility gauge is designed for commercial and industrial applications. This black steel gauge was designed with anti-vibration technology making it extremely durable while being certified for accuracy by NIST standards.

Specifications:
  • Non-Liquid
  • Lens: Glass
  • Case: black steel
  • Pointer: black aluminum
  • Bezel: black painted steel
  • Wetted Parts: copper alloy
  • Connection: center back mount
  • Scale: Standard psi/BAR (x100 = kPa)
  • Ambient Temperature: -50º F to 160º F
  • Accuracy: 3-2-3% of span, ASME B40.1 Grade B


Details

Dial Size

2.0" (50 mm)

Face

White Aluminum with Black/Blue Print

Housing Material

Black Steel

Internal Component Material

Brass

Lens

Plastic

Mounting Options

Center Back

Operating Pressure Range

0 - 160 psi

Operating Temperature Range

30°F to 160°F

Pointer

Aluminum - Black

Accuracy

B (3-2-3%)

Wetted Materials

Copper Alloy

Fluid

Glycerine and water

Units Of Measure (Psi, Bars, Hgvac)

PSI/Bars


Water





The 91B20-C4-43B-160P is a center mount pressure gauge that features a black steel case with copper alloy internals. This easy-to-read utility gauge is designed for commercial and industrial applications. This black steel gauge was designed with anti-vibration technology making it extremely durable while being certified for accuracy by NIST standards.

Specifications:
  • Non-Liquid
  • Lens: Glass
  • Case: black steel
  • Pointer: black aluminum
  • Bezel: black painted steel
  • Wetted Parts: copper alloy
  • Connection: center back mount
  • Scale: Standard psi/BAR (x100 = kPa)
  • Ambient Temperature: -50º F to 160º F
  • Accuracy: 3-2-3% of span, ASME B40.1 Grade B

Details

Dial Size

2.0" (50 mm)

Face

White Aluminum with Black/Blue Print

Housing Material

Black Steel

Internal Component Material

Brass

Lens

Plastic

Mounting Options

Center Back

Operating Pressure Range

0 - 160 psi

Operating Temperature Range

30°F to 160°F

Pointer

Aluminum - Black

Accuracy

B (3-2-3%)

Wetted Materials

Copper Alloy

Fluid

Glycerine and water

Units Of Measure (Psi, Bars, Hgvac)

PSI/Bars

Documentation
Water
