Water Pressure Gauge 1000 PSI, 1/4" MPT, 2.5" Plastic Dial, Center Mount, SS Case

The 91A25-C4-43B-1000P is a center mount pressure gauge that features a stainless steel case with copper alloy internals. This stainless steel gauge is glycerine filled with a polycarbonate lens. This easy-to-read utility gauge is designed for commercial and industrial applications where vibration or pulsation is present.

Specifications:

Glycerine filled
Lens: polycarbonate
Case: stainless steel
Pointer: black aluminum
Bezel: stainless steel, fixed
Wetted Parts: copper alloy
Connection: center back mount
Scale: Standard psi/BAR (x100 = kPa)
Ambient Temperature: 30º F to 160º F
Accuracy: 2-1-2% ASME B40.1 Grade A

Compatible with:

AXEON/RO Ultratec

201360

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Accuracy	A (2-1-2%)
Dial Size	2-1/2" (63 mm)
Face	White Aluminum with Black/Blue Print
Fluid	Glycerine and water
Housing Material	Stainless Steel
Max Pressure (Psi)	1000
Min Pressure (Psi)	0
Pointer	Aluminum - Black
Units Of Measure (Psi, Bars, Hgvac)	PSI/Bars
Accuracy Grade	A Grade: 2-1-2%
Case Filling	Glycerine
Case Type	Stainless Steel
Connection Type	1/4" MPT
Gauge Bezel	Plastic Fixed
Gauge Lens	Plastic
Mounting Style	Center Back Mount
Pressure Rating	1000 PSI
Type	Center Mount
Wetted Parts	Copper Alloy (Brass)
Shipping Dimensions
Shipping Length	2.75 in.
Shipping Width	2.75 in.
Shipping Height	2.75 in.
Product Weight & Dimensions
Product Weight (lbs)	0.55
