GE Water

TFM Encapsulated Module (100 GPD) w/Check Valve & NO Flow Control

Part Number: TFM-100EN

Alt. Part Number: 1225828, TLC-150, 1234408

In Stock

out of stock

In Stock

$43.50


GE TFM-100-CV is a 100 Gallon per Day Encapsulated Reverse Osmosis Membrane which includes a Control Valve. It has a built-in permeate check-valve which eliminates the need for additional fittings and reduces the potential for water leaks within the system. Unlike conventional filtration which can be maintenance-intensive, membrane-separation technology uses crossflow filtration where impurities are captured on the membrane and are constantly swept away by the concentrate stream. Thus the membrane surface is continuously cleaned, which prolongs the life of the membrane and reduces maintenance costs.The spiral-wound membrane element is constructed of one or more membrane envelopes which are wound around a perforated central tube. The permeate water passes through the reverse osmosis membrane into the envelope and spirals inward to the central tube.
Features:
  • ANSI/NSF 58 listed for material safety, structural integrity & for performance
  • Color-coded ports and quick connect fittings for easy connection to an existing system
  • Check-valve
  • Membrane-separation technology
  • Thin-Film Membrane
NOTE: This Membrane is not chlorine resistant. A CTO reduction water filter must be used before the RO membrane if chlorine is present in your water supply


Weight & Dimensions

Approx Length (Inches)

13.25 Inches

Details

Capacity

24 - 36 months

Cartridge Style

Encapsulated

Diameter

2.5 Inches

Features

Check Valve

Flow Rate

100 Gallons per day

Inner/Outer Wraps

Tape

Max Operating Pressure

90 PSI

Max Operating Temperature

120 Degrees Fahrenheit

Average Nacl Rejection

96 Percent

Warranty & Certifications

Certifications

ANSI/NSF 58


TFM





GE TFM-100-CV is a 100 Gallon per Day Encapsulated Reverse Osmosis Membrane which includes a Control Valve. It has a built-in permeate check-valve which eliminates the need for additional fittings and reduces the potential for water leaks within the system. Unlike conventional filtration which can be maintenance-intensive, membrane-separation technology uses crossflow filtration where impurities are captured on the membrane and are constantly swept away by the concentrate stream. Thus the membrane surface is continuously cleaned, which prolongs the life of the membrane and reduces maintenance costs.The spiral-wound membrane element is constructed of one or more membrane envelopes which are wound around a perforated central tube. The permeate water passes through the reverse osmosis membrane into the envelope and spirals inward to the central tube.
Features:
  • ANSI/NSF 58 listed for material safety, structural integrity & for performance
  • Color-coded ports and quick connect fittings for easy connection to an existing system
  • Check-valve
  • Membrane-separation technology
  • Thin-Film Membrane
NOTE: This Membrane is not chlorine resistant. A CTO reduction water filter must be used before the RO membrane if chlorine is present in your water supply

Weight & Dimensions

Approx Length (Inches)

13.25 Inches

Details

Capacity

24 - 36 months

Cartridge Style

Encapsulated

Diameter

2.5 Inches

Features

Check Valve

Flow Rate

100 Gallons per day

Inner/Outer Wraps

Tape

Max Operating Pressure

90 PSI

Max Operating Temperature

120 Degrees Fahrenheit

Average Nacl Rejection

96 Percent

Warranty & Certifications

Certifications

ANSI/NSF 58
