Colder SMC Series Couplings are designed with the latest Colder technology called Twist-to-Connect. The quarter-turn latch clicks to ensure that your connection is secure and allows tubing to rotate freely. SMC Series Couplings are among the smallest couplings offered by Colder and are constructed from a variety of different materials such as acetal, polypropylene, and ABS plastic.
Specifications
Specifications
- Material: Acetal
- Color: Molded Black
- Pressure Range: Vacuum to 100 psi, 6.9 bar
- Mounting Option: Free Floating
- Valve Option: Non-Valved
- Temperature Range: -40º F to 180º F
- Available in Bags of 50 units
Weight & Dimensions
Length (inches) | 0.88 |
Height (inches) | 0.25 |
Width (inches) | 0.25 |
Weight (lbs) | 0.000625 |
Details
Series | SMC |
Max Temp (°F) | 180 |
Max Pressure (Psi) | 100 |
Min Temp (°F) | -40 |
Min Pressure (Psi) | Vacuum |
Barb Size | 1/8" ID |
Application | Water |
Bag Quantity | 50 |
Body Material | Acetal Copolymer |
Color / Finish | Black |
Mounting Options | Free Floating |
Origin | USA |
Spring | 316 Stainless steel |
Valve Type | Non-Valved |
Colder SMC Series Couplings are designed with the latest Colder technology called Twist-to-Connect. The quarter-turn latch clicks to ensure that your connection is secure and allows tubing to rotate freely. SMC Series Couplings are among the smallest couplings offered by Colder and are constructed from a variety of different materials such as acetal, polypropylene, and ABS plastic.
Specifications
- Material: Acetal
- Color: Molded Black
- Pressure Range: Vacuum to 100 psi, 6.9 bar
- Mounting Option: Free Floating
- Valve Option: Non-Valved
- Temperature Range: -40º F to 180º F
- Available in Bags of 50 units
Weight & Dimensions
Length (inches) | 0.88 |
Height (inches) | 0.25 |
Width (inches) | 0.25 |
Weight (lbs) | 0.000625 |
Details
Series | SMC |
Max Temp (°F) | 180 |
Max Pressure (Psi) | 100 |
Min Temp (°F) | -40 |
Min Pressure (Psi) | Vacuum |
Barb Size | 1/8" ID |
Application | Water |
Bag Quantity | 50 |
Body Material | Acetal Copolymer |
Color / Finish | Black |
Mounting Options | Free Floating |
Origin | USA |
Spring | 316 Stainless steel |
Valve Type | Non-Valved |
