SHURflo

SHURflo 8005-243-256 Demand Pump 1.4 gpm 60 psi 12VDC

Part Number: 8005-243-256

In Stock

out of stock

In Stock

$74.69

The SHURflo 8005-243-256 Demand Pump is ideal in applications that require high pressure and a flow rate of 1.4 GPM. The pump can be mounted in any position, is compact and is designed for long trouble-free life.

Specification:
  • 1.4 GPM flow rate
  • Pressure Switch (on at 45 psi, off at 60 psi)
  • Max Inlet Pressure: 30 psi
  • Can run dry without damage
  • Self priming up 10 vertical feet
  • 3/8" NPT female ports
  • Santoprene diaphragm
  • Built-in check valve
  • UL Recognized Component
  • NSF and CSA listed
Applications:
  • Water delivery




Weight & Dimensions

Approx Height (Inches)

4.08"

Approx Length (Inches)

7.56"

Approx Width (Inches)

3.28"

Weight (lbs)

4.3

Details

Amps

2.1-4.7 Amps @ 0-60 PSI

Diaphragm Materials

Santoprene

Inlet/Outlet Connection

3/8" FPT

Inlet Pressure

30 PSI

Power Source

None

Pressure Switch

60 PSI

Psi Bypass

45-60 PSI

Series

8000

Size

3/8"

Suction Lift

Self prime up to 10 ft

Wire Option

Bare Wire

Connection Type

Female (FPT)

Flow Rate

1.4 GPM

Type

Diaphragm Pump

Voltage

12VDC


SHURflo

SHURflo

SHURflo




The SHURflo 8005-243-256 Demand Pump is ideal in applications that require high pressure and a flow rate of 1.4 GPM. The pump can be mounted in any position, is compact and is designed for long trouble-free life.

Specification:
  • 1.4 GPM flow rate
  • Pressure Switch (on at 45 psi, off at 60 psi)
  • Max Inlet Pressure: 30 psi
  • Can run dry without damage
  • Self priming up 10 vertical feet
  • 3/8" NPT female ports
  • Santoprene diaphragm
  • Built-in check valve
  • UL Recognized Component
  • NSF and CSA listed
Applications:
  • Water delivery



Weight & Dimensions

Approx Height (Inches)

4.08"

Approx Length (Inches)

7.56"

Approx Width (Inches)

3.28"

Weight (lbs)

4.3

Details

Amps

2.1-4.7 Amps @ 0-60 PSI

Diaphragm Materials

Santoprene

Inlet/Outlet Connection

3/8" FPT

Inlet Pressure

30 PSI

Power Source

None

Pressure Switch

60 PSI

Psi Bypass

45-60 PSI

Series

8000

Size

3/8"

Suction Lift

Self prime up to 10 ft

Wire Option

Bare Wire

Connection Type

Female (FPT)

Flow Rate

1.4 GPM

Type

Diaphragm Pump

Voltage

12VDC
