- Unique element design traps sediment in lower reservoir of clear cover.
- Clear bowl easily removed for total cleaning (no tools required-using tools voids warranty)
- Sediment is visible through the clear cover indicating when the filter needs cleaning
- Ball valve allows for quick sediment removal from bottom of cover
- Centrifuge Spin-Down type sediment separation
- No down time!!
- The new 1.5" and 2" spin-down models make it easy to convert the standard spin-down filter to a sediment trapper by simply replacing the element screens
- No filter cartridges to replace
- No down time required flushing out sediment
- No wasteful backwashing required
- Small size takes little space
- Screen sizes can be easily changed if required
- Multiple uses: well water, irrigation, sand sensitive valves, drip irrigation, faucet aerators, poultry growers watering devices (.010"), fogger nozzles, pre-treatment for ultra water systems and reverse osmosis
Details
Body Material | PVC |
Head Style | T-Style |
Housing Material | Chemical/Heat Resistant High Impact Polymer Resin |
Inlet/Outlet Connection | 1-1/2" Slip |
Max Pressure (Psi) | 150 |
Max Temp (°F) | 100 |
Mesh Size | 30, 60, 100, 140, 250, 500, 1000, 24, 40 |
Micron Rating (Nominal) | 533 µm, 254 µm, 152 µm, 104 µm, 61 µm, 30 µm, 15 µm, 711 µm, 381 µm |
O-Rings | EPDM |
Screen Opening | .021, .010, .006, .004, .0024, .0012, .0006, .0029 |
Cartridge Style | Sediment Trapper |
Connection Type | Slip |
Contaminants Reduced | Sediment/Dirt/Rust |
Filter Type | Rusco Spin-Down & Sediment Traps |
Flow Rate | 10-50 GPM |
Media Type | Chemical Resistant Polyester |
Micron Rating | 533 µm, 254 µm, 152 µm, 104 µm, 61 µm, 30 µm, 15 µm, 711 µm, 381 µm |
Port Size | 1-1/2" |
Screen Material | Polyester |
Sub-Type | T-Style System |
Top Style | T-Style |
Type | Sediment Trapper |
Features:
- Unique element design traps sediment in lower reservoir of clear cover.
- Clear bowl easily removed for total cleaning (no tools required-using tools voids warranty)
- Sediment is visible through the clear cover indicating when the filter needs cleaning
- Ball valve allows for quick sediment removal from bottom of cover
- Centrifuge Spin-Down type sediment separation
- No down time!!
- The new 1.5" and 2" spin-down models make it easy to convert the standard spin-down filter to a sediment trapper by simply replacing the element screens
- No filter cartridges to replace
- No down time required flushing out sediment
- No wasteful backwashing required
- Small size takes little space
- Screen sizes can be easily changed if required
- Multiple uses: well water, irrigation, sand sensitive valves, drip irrigation, faucet aerators, poultry growers watering devices (.010"), fogger nozzles, pre-treatment for ultra water systems and reverse osmosis
Details
Body Material | PVC |
Head Style | T-Style |
Housing Material | Chemical/Heat Resistant High Impact Polymer Resin |
Inlet/Outlet Connection | 1-1/2" Slip |
Max Pressure (Psi) | 150 |
Max Temp (°F) | 100 |
Mesh Size | 30, 60, 100, 140, 250, 500, 1000, 24, 40 |
Micron Rating (Nominal) | 533 µm, 254 µm, 152 µm, 104 µm, 61 µm, 30 µm, 15 µm, 711 µm, 381 µm |
O-Rings | EPDM |
Screen Opening | .021, .010, .006, .004, .0024, .0012, .0006, .0029 |
Cartridge Style | Sediment Trapper |
Connection Type | Slip |
Contaminants Reduced | Sediment/Dirt/Rust |
Filter Type | Rusco Spin-Down & Sediment Traps |
Flow Rate | 10-50 GPM |
Media Type | Chemical Resistant Polyester |
Micron Rating | 533 µm, 254 µm, 152 µm, 104 µm, 61 µm, 30 µm, 15 µm, 711 µm, 381 µm |
Port Size | 1-1/2" |
Screen Material | Polyester |
Sub-Type | T-Style System |
Top Style | T-Style |
Type | Sediment Trapper |
