Norgren

Norgren R06-221-NNEA Non-Relieving Water/Air Regulator 1/4 FPT

Part Number: R06221NNEA

Alt. Part Number: R06

In Stock

out of stock

In Stock

$34.85

The Norgren R06-221-NNEA water and air pressure regulator features a compact corrosion resistant design.  The R06-221-NNEA has a snap action pressure adjusting knob that locks the pressure setting when the knob is pushed in.  This regulator is suitable for use on air or water service.

Specifications:
  • Compact design
  • Corrosion resistant construction
  • Brass body with plastic bonnet
  • Non-relieving model; designed for water and air service
  • For industrial applications only; not designed for use with deionized or potable water
  • Port size: 1/4" FPT
  • Max inlet pressure: 400 psig (28 Bar)
  • Max outlet pressure: 50 psig (3.5 Bar)
  • Outlet pressure adjustable from 5-50 psig (0.3-3.5 Bar)
  • Max flow rate (water): 1.3 gpm
  • Max flow rate (air): 12.0 SCFM
Air supply must be dry enough to avoid ice formation at temperatures below 35°F (2°C)



Weight & Dimensions

Approx Height (Inches)

2.86 Inches

Approx Length (Inches)

1.57 Inches

Details

Body Material

Brass

Flow Rate

1.3

Operating Temperature Range

Water: 35-150 Air -30-150 Degrees Fahrenheit

Port Size

1/8" FPT Inches, 1/4" FNPT

Seat

Acetal Resin

Max Inlet Pressure

400 psig (28 Bar) PSI

Max Outlet Pressure

50 psig (3.5 Bar)

Outlet Pressure

5-50 psig (0.3-3.5 Bar) PSI


Norgren

Norgren




The Norgren R06-221-NNEA water and air pressure regulator features a compact corrosion resistant design.  The R06-221-NNEA has a snap action pressure adjusting knob that locks the pressure setting when the knob is pushed in.  This regulator is suitable for use on air or water service.

Specifications:
  • Compact design
  • Corrosion resistant construction
  • Brass body with plastic bonnet
  • Non-relieving model; designed for water and air service
  • For industrial applications only; not designed for use with deionized or potable water
  • Port size: 1/4" FPT
  • Max inlet pressure: 400 psig (28 Bar)
  • Max outlet pressure: 50 psig (3.5 Bar)
  • Outlet pressure adjustable from 5-50 psig (0.3-3.5 Bar)
  • Max flow rate (water): 1.3 gpm
  • Max flow rate (air): 12.0 SCFM
Air supply must be dry enough to avoid ice formation at temperatures below 35°F (2°C)


Weight & Dimensions

Approx Height (Inches)

2.86 Inches

Approx Length (Inches)

1.57 Inches

Details

Body Material

Brass

Flow Rate

1.3

Operating Temperature Range

Water: 35-150 Air -30-150 Degrees Fahrenheit

Port Size

1/8" FPT Inches, 1/4" FNPT

Seat

Acetal Resin

Max Inlet Pressure

400 psig (28 Bar) PSI

Max Outlet Pressure

50 psig (3.5 Bar)

Outlet Pressure

5-50 psig (0.3-3.5 Bar) PSI
