Specifications:
- Micron Rating: 0.2 micron absolute
- End Caps: 222/fin
- Filter Dimensions: 20" L x 2.67" OD
- Absolute rated retention efficiency
- All materials comply with FDA requirements for food contact
- Not integrity tested - cost-effective absolute filtration for less critical applications
- Filter Media: asymmectric polyethersulfone
- 6 square feet of media surface area
- Made in USA
Compatible with:
| Graver Technologies | ZTECWB0.2-20P8S |
Weight & Dimensions
Weight (lbs) | 1.5 |
Approx Length (Inches) | 20" (50.8 cm) |
Details
Capacity | As Needed |
Inner/Outer Wraps | Polypropylene |
Max Temp (°F) | 176 |
Micron Rating (Absolute) | 0.2 µm |
O-Rings | Silicone |
Surface Area | 14.4 Square Feet |
Cap Material | 222/Fin |
Change Frequency | As Needed |
Contaminants Reduced | Sediment/Dirt/Rust |
Diameter | 2-2/3" |
End Cap Type | SOE 222 Oring & Fin |
Inner Diameter | 1" |
Media Type | Asymmetric Polyethersulfone |
Micron Rating | 0.2 µm ABS |
Origin | USA |
Product Length | 20" |
Warranty & Certifications
Certifications | FDA CFR-21 |
Neo-Pure HP-PESW High Purity Polyethersulfone Water Grade Membranes are manufactured in the USA in a state-of-the-art white room. They provide absolute-rated retention efficiency for high purity applications. HP-PESW Series filters are not integrity tested, making them a cost-effective absolute filtration option for less critical applications. All filter materials comply with the FDA CFR criteria for food and beverage contact and meet USP Class VI Biological Testing for plastics.
Specifications:
- Micron Rating: 0.2 micron absolute
- End Caps: 222/fin
- Filter Dimensions: 20" L x 2.67" OD
- Absolute rated retention efficiency
- All materials comply with FDA requirements for food contact
- Not integrity tested - cost-effective absolute filtration for less critical applications
- Filter Media: asymmectric polyethersulfone
- 6 square feet of media surface area
- Made in USA
Compatible with:
| Graver Technologies | ZTECWB0.2-20P8S |
Weight & Dimensions
Weight (lbs) | 1.5 |
Approx Length (Inches) | 20" (50.8 cm) |
Details
Capacity | As Needed |
Inner/Outer Wraps | Polypropylene |
Max Temp (°F) | 176 |
Micron Rating (Absolute) | 0.2 µm |
O-Rings | Silicone |
Surface Area | 14.4 Square Feet |
Cap Material | 222/Fin |
Change Frequency | As Needed |
Contaminants Reduced | Sediment/Dirt/Rust |
Diameter | 2-2/3" |
End Cap Type | SOE 222 Oring & Fin |
Inner Diameter | 1" |
Media Type | Asymmetric Polyethersulfone |
Micron Rating | 0.2 µm ABS |
Origin | USA |
Product Length | 20" |
Warranty & Certifications
Certifications | FDA CFR-21 |
