Multi-Mount couplings provide one easy-to-use coupling for connecting three to five lines at one time. Multi-mounts are available in either acetal or chrome plated brass and are keyed to prevent mismatched connections.
Specifications:
Specifications:
- Material: Brass
- Material Finish: Chrome
- Color: Chrome
- Valve Option: Valved
- Mounting Option: Free Floating
- Temperature Range: -40°F to 180°F (-40°C to 82°C)
Weight & Dimensions
Weight (lbs) | 0.5 |
Details
Application | Water |
Barb Size | 3/8" ID |
Body Material | Chrome-Plated Brass |
Max Pressure (Psi) | 500 |
Max Temp (°F) | 180 |
Min Pressure (Psi) | Vacuum |
Min Temp (°F) | -40 |
Mounting Options | Panel Mount |
Seal Material | Buna-N |
Series | Multi-Mount, LM |
Spring | 316 Stainless Steel |
Valve Type | Valved |
Color / Finish | Chrome |
Type | Coupling Insert |
Multi-Mount couplings provide one easy-to-use coupling for connecting three to five lines at one time. Multi-mounts are available in either acetal or chrome plated brass and are keyed to prevent mismatched connections.
Specifications:
- Material: Brass
- Material Finish: Chrome
- Color: Chrome
- Valve Option: Valved
- Mounting Option: Free Floating
- Temperature Range: -40°F to 180°F (-40°C to 82°C)
Weight & Dimensions
Weight (lbs) | 0.5 |
Details
Application | Water |
Barb Size | 3/8" ID |
Body Material | Chrome-Plated Brass |
Max Pressure (Psi) | 500 |
Max Temp (°F) | 180 |
Min Pressure (Psi) | Vacuum |
Min Temp (°F) | -40 |
Mounting Options | Panel Mount |
Seal Material | Buna-N |
Series | Multi-Mount, LM |
Spring | 316 Stainless Steel |
Valve Type | Valved |
Color / Finish | Chrome |
Type | Coupling Insert |
