LMD12006 Multi-Mount Valved Coupling Body 3/8 PTF

Multi-Mount couplings provide one easy-to-use coupling for connecting three to five lines at one time. Multi-mounts are available in either acetal or chrome plated brass and are keyed to prevent mismatched connections.

Specifications:

Material: Brass
Material Finish: Nickel
Color: Chrome
Valve Option: Valved
Mounting Option: Panel Mount
Pressure Range: 500psi / no. of stations
Temperature Range: -40°F to 180°F (-40°C to 82°C)

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Application	Water
Body Material	Chrome-Plated Brass
Inlet Connection	3/8" FPT
Max Pressure (Psi)	500
Max Temp (°F)	180
Min Pressure (Psi)	Vacuum
Min Temp (°F)	-40
Mounting Options	Panel Mount
Nsf Version	No
Outlet Connection	3/8" FPT
Push-In Size	3/8" OD
Seal Material	Buna-N
Series	Multi-Mount LM
Shape	Straight
Size	3/8"
Spring	316 Stainless Steel
Valve Type	Valved
Color / Finish	Chrome
Connection Type	Female (FPT)
Type	Coupling Body

Product Details
Application	Water
Body Material	Chrome-Plated Brass
Inlet Connection	3/8" FPT
Max Pressure (Psi)	500
Max Temp (°F)	180
Min Pressure (Psi)	Vacuum
Min Temp (°F)	-40
Mounting Options	Panel Mount
Nsf Version	No
Outlet Connection	3/8" FPT
Push-In Size	3/8" OD
Seal Material	Buna-N
Series	Multi-Mount LM
Shape	Straight
Size	3/8"
Spring	316 Stainless Steel
Valve Type	Valved
Color / Finish	Chrome
Connection Type	Female (FPT)
Type	Coupling Body
