- Black acetal copolymer construction
- Nitrile O-rings
- FDA approved materials
- NSF Certified 51 & 61
- Suitable for water, air, inert gases
- And pneumatic applications or vacuum
Weight & Dimensions
Box Dimensions | 10.5x21.5x12 |
Case Dimensions | 10.5x21.5x12 |
Height (inches) | 2.25 |
Length (inches) | 2.25 |
Weight (lbs) | 0.003125 |
Width (inches) | 0.75 |
Details
Application | Water, Air |
Body Material | Acetal Copolymer |
Max Pressure (Psi) | 150 |
Max Temp (°F) | 150 |
Min Pressure (Psi) | 0 |
Min Temp (°F) | -4 |
Mounting Options | Free Floating |
Push-In Size | 12mm OD |
Seal Material | Buna-N |
Series | PM |
Color / Finish | Black |
Sub-Type | Union Coupling |
Type | Coupling |
Warranty & Certifications
Certifications | NSF 61; NSF 51; FDA Approved; NSF 372 |
Features:
- Black acetal copolymer construction
- Nitrile O-rings
- FDA approved materials
- NSF Certified 51 & 61
- Suitable for water, air, inert gases
- And pneumatic applications or vacuum
California residents
WARNING!
This product contains arsenic known to the State of California to cause cancer and birth defects or other reproductive harm.
Weight & Dimensions
Box Dimensions | 10.5x21.5x12 |
Case Dimensions | 10.5x21.5x12 |
Height (inches) | 2.25 |
Length (inches) | 2.25 |
Weight (lbs) | 0.003125 |
Width (inches) | 0.75 |
Details
Application | Water, Air |
Body Material | Acetal Copolymer |
Max Pressure (Psi) | 150 |
Max Temp (°F) | 150 |
Min Pressure (Psi) | 0 |
Min Temp (°F) | -4 |
Mounting Options | Free Floating |
Push-In Size | 12mm OD |
Seal Material | Buna-N |
Series | PM |
Color / Finish | Black |
Sub-Type | Union Coupling |
Type | Coupling |
Warranty & Certifications
Certifications | NSF 61; NSF 51; FDA Approved; NSF 372 |
