HFC24635BSPT Male Thread Coupling Insert 3/8 BSPT

The HFC35 Series couplings are able to withstand demanding applications and feature physical strength, chemical resistance and autoclavability.

Specifications:

Material: Polysulfone
Material Finish: Molded Black
Color: Black
Pressure Range: Vacuum to 125 psi, 8.6 bar
Mounting Option: BSPT threads
Valve Option: Non-Valved
Temperature Range: -40ºF to 280ºF
Seal Options: EPDM

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Application	Water
Body Material	Polysulfone
External Springs And Pin	316 Stainless Steel
Inlet Connection	3/8" BSP
Max Pressure (Psi)	125
Max Temp (°F)	280
Min Pressure (Psi)	Vacuum
Min Temp (°F)	-40
Mounting Options	Thread
Nsf Version	No
Outlet Connection	3/8" BSP
Seal Material	EPDM
Series	HFC35
Shape	Straight
Size	3/8"
Spring	316 stainless steel
Valve Type	Non-Valved
Color / Finish	White Black
Connection Type	BSP
Type	Coupling
Product Weight & Dimensions
Product Weight (lbs)	0.1

Product Details
Application	Water
Body Material	Polysulfone
External Springs And Pin	316 Stainless Steel
Inlet Connection	3/8" BSP
Max Pressure (Psi)	125
Max Temp (°F)	280
Min Pressure (Psi)	Vacuum
Min Temp (°F)	-40
Mounting Options	Thread
Nsf Version	No
Outlet Connection	3/8" BSP
Seal Material	EPDM
Series	HFC35
Shape	Straight
Size	3/8"
Spring	316 stainless steel
Valve Type	Non-Valved
Color / Finish	White Black
Connection Type	BSP
Type	Coupling
Product Weight & Dimensions
Product Weight (lbs)	0.1
