Axeon

AXEON HF5-4021 1000 GPD RO Membrane Element

Part Number: 200393

In Stock

out of stock

In Stock

$258.24

The AXEON HF5-4021 Reverse Osmosis Membranes are one of the industries most reliable and highest performing reverse osmosis elements. The HF5-4021 RO membrane elements are available in all standard commercial sizes, feature a protective tape wound exterior, and are 100% vacuum integrity tested.The polyamide thin-film used in the AXEON HF5 Series membranes is manufactured by a major US membrane film manufacturer.

Specifications:
  • Permeate Flow Rate: 1000 gallons per day
  • Membrane Type: Polyamide Thin-Film
  • Applied Pressure: 80 psi
  • Dimensions: 4" x 21"
  • Minimum Concentrate Flow Rate: 5:1
  • Chlorine Tolerance: 0 ppm
  • Maximum Operating Temperature: 113° F
  • Applications: Extra Low Energy, Brackish Water
  • Formerly known as RO UltraTec HF5-4021




Weight & Dimensions

Box Quantity

1

Height (inches)

4.5

Length (inches)

21

Weight (lbs)

3.96

Width (inches)

4.5

Details

Application

Brackish Water

Average Nacl Rejection

0.98

Chlorine Tolerance

0 ppm

Cleaning Ph Range

1-13

Direction

Outside - In

Feed Water Temperature

77°F

Inlet Pressure

80 PSI

Inner/Outer Wraps

Tape

Material Of Construction

Polyamide Thin-Film

Max Feed Silt Density Index

5 Silt Density Index

Max Feed Water Turbidity

1 Nephelometric Turbidity Units

Max Pressure Drop

10 PSI Differential

Max Pressure (Psi)

400psi

Max Temp (°F)

113°F

Membrane Type

Spiral Wound

Minimum Salt Rejection Ci- (%)

0.96

Permeate Flow Rate

1000 gpd / (3.79 m³/d)

Permeate Tube Diameter

3/4"

Ph Range

2-11

Recovery Rate

0.15

Stabilized Salt Rejection Ci- (%)

0.985

Diameter

3.95"

Product Length

21"


AXEON




The AXEON HF5-4021 Reverse Osmosis Membranes are one of the industries most reliable and highest performing reverse osmosis elements. The HF5-4021 RO membrane elements are available in all standard commercial sizes, feature a protective tape wound exterior, and are 100% vacuum integrity tested.The polyamide thin-film used in the AXEON HF5 Series membranes is manufactured by a major US membrane film manufacturer.

Specifications:
  • Permeate Flow Rate: 1000 gallons per day
  • Membrane Type: Polyamide Thin-Film
  • Applied Pressure: 80 psi
  • Dimensions: 4" x 21"
  • Minimum Concentrate Flow Rate: 5:1
  • Chlorine Tolerance: 0 ppm
  • Maximum Operating Temperature: 113° F
  • Applications: Extra Low Energy, Brackish Water
  • Formerly known as RO UltraTec HF5-4021



Weight & Dimensions

Box Quantity

1

Height (inches)

4.5

Length (inches)

21

Weight (lbs)

3.96

Width (inches)

4.5

Details

Application

Brackish Water

Average Nacl Rejection

0.98

Chlorine Tolerance

0 ppm

Cleaning Ph Range

1-13

Direction

Outside - In

Feed Water Temperature

77°F

Inlet Pressure

80 PSI

Inner/Outer Wraps

Tape

Material Of Construction

Polyamide Thin-Film

Max Feed Silt Density Index

5 Silt Density Index

Max Feed Water Turbidity

1 Nephelometric Turbidity Units

Max Pressure Drop

10 PSI Differential

Max Pressure (Psi)

400psi

Max Temp (°F)

113°F

Membrane Type

Spiral Wound

Minimum Salt Rejection Ci- (%)

0.96

Permeate Flow Rate

1000 gpd / (3.79 m³/d)

Permeate Tube Diameter

3/4"

Ph Range

2-11

Recovery Rate

0.15

Stabilized Salt Rejection Ci- (%)

0.985

Diameter

3.95"

Product Length

21"
