3M Fluid Purification

3M BetaPure Polyolefin Filter 20 mic Absolute (5 mic Nominal) - 29-1/4

Part Number: AU29B11NG

In Stock

out of stock

In Stock

$56.39


Betapure filter manufacturing utilizes state-of-the-art technology to produce a clean, rigid, filter structure with consistent and reproducable filtration characteristics. The filter matrix is constructed using long bicomponents fibers, each fiber having an inner core and an outer sheath. The bicomponent fibers of the filter matrix are thermally bonded by utilizing the difference in melt temperatures of the two fiber components. Heating the matrix to the melt temperature of the polyethylene sheath, but below that of the polypropylene core, causes the fiber-to-fiber bond at every contact point. The high degree of fiber-to-fiber bonding provides a rigid structure that eliminates the need for a core support and any possibility of media migration.
Specifications:
  • 99.9% efficient @ 5 mic
  • Absolute Ratings
  • Rigid Structure
  • Depth Filtration
  • Patented Gasket Design
  • Lower Pressure Drop
 Applications:
  • Coatings - Magnetic Media, High Quality Paint, Film Coatings, Resins and Ink
  • Food & Beverage - Bottled Water, Pre RO, Blend Water & Wash Water
  • General Industrial - Desalination, Plating, Machine Tool Coolant and Process Water
  • Pharmaceutical - Water, Solvents, Chemicals, Pre RO, Antibiotic Intermediate Production
  • Electronics - Pre RO, Water Slurries, Ceramic Slurries, Chemical Mechanical Polishing, Cathode Ray Tube Production & Disc Cleaning
  • Chemical/Petro-Chemical - Process Water, Pre RO, Amine, Fine Chemicals & MTBE
The Betapure filter ensures that the unwanted particles are removed because:
  • The rigid structure maintains its porosity throughout the filter life.
  • The depth structure removes more difficult deformable contaminants.
3M Beta Pure AU29B11NG Ordering Guide


Weight & Dimensions

Approx Length (Inches)

29 1/4" (74.3 cm)

Details

Capacity

As Needed

Case Quantity

15

Media Type

Polyolefin

Micron Rating (Absolute)

20 Micron

Micron Rating (Nominal)

5 Micron


3M





Betapure filter manufacturing utilizes state-of-the-art technology to produce a clean, rigid, filter structure with consistent and reproducable filtration characteristics. The filter matrix is constructed using long bicomponents fibers, each fiber having an inner core and an outer sheath. The bicomponent fibers of the filter matrix are thermally bonded by utilizing the difference in melt temperatures of the two fiber components. Heating the matrix to the melt temperature of the polyethylene sheath, but below that of the polypropylene core, causes the fiber-to-fiber bond at every contact point. The high degree of fiber-to-fiber bonding provides a rigid structure that eliminates the need for a core support and any possibility of media migration.
Specifications:
  • 99.9% efficient @ 5 mic
  • Absolute Ratings
  • Rigid Structure
  • Depth Filtration
  • Patented Gasket Design
  • Lower Pressure Drop
 Applications:
  • Coatings - Magnetic Media, High Quality Paint, Film Coatings, Resins and Ink
  • Food & Beverage - Bottled Water, Pre RO, Blend Water & Wash Water
  • General Industrial - Desalination, Plating, Machine Tool Coolant and Process Water
  • Pharmaceutical - Water, Solvents, Chemicals, Pre RO, Antibiotic Intermediate Production
  • Electronics - Pre RO, Water Slurries, Ceramic Slurries, Chemical Mechanical Polishing, Cathode Ray Tube Production & Disc Cleaning
  • Chemical/Petro-Chemical - Process Water, Pre RO, Amine, Fine Chemicals & MTBE
The Betapure filter ensures that the unwanted particles are removed because:
  • The rigid structure maintains its porosity throughout the filter life.
  • The depth structure removes more difficult deformable contaminants.
3M Beta Pure AU29B11NG Ordering Guide

Weight & Dimensions

Approx Length (Inches)

29 1/4" (74.3 cm)

Details

Capacity

As Needed

Case Quantity

15

Media Type

Polyolefin

Micron Rating (Absolute)

20 Micron

Micron Rating (Nominal)

5 Micron
