3M Fluid Purification

3M Betapure NT40T010S0BB NT-T Series 40" Filter 226/Spear 1 micron ABS (Case of 15)

Part Number: NT40T010S0BB:15PK

In Stock

out of stock

In Stock

$2,861.75


The Betapure NT-T Series cartridges are designed to provide superior service life while also delivering a consistent filtration efficiency. The filters combine polypropylene media with fluid distribution netting to form multiple layers. This allows for greater fluid movement from layer to layer as it passes through the three distinct media sections.

Specifications:
  • Case of 15 filters
  • End Caps: 226 o-ring with spear
  • O-ring Material: fluorocarbon
  • Filter Dimensions: 40" L x 2-1/2" OD
  • Micron Rating: 1 micron absolute
  • Tested and certified by WQA to NSF/ANSI Standard 61 for material requirements only
Applications:
  • Chemical and hydrocarbon processing - acids, bleach (sodium hypochlorite), polyethylene and polypropylene manufacture, amine sweetening and waterflood
  • Food and beverage applications - bottled water particulate and turbidity reduction, reverse osmosis membrane and spray nozzle protection, diatomaceous earth or carbon fine trap, beverage blending, rinsing and water water
  • Fine chemical and electronics - pre-RO filtration of high silt density index incoming water, copper sulfate plating bath filtration in printed circuit board construction, color screen filtration for CRT production
  • Coating - film and paper coatings, photographic film, lens coatings, can coatings, high quality paints and ink
  • Industrial - machine tool lubrication, chemicals, detergents, waste water, textiles, plating baths, pulp and paper, process water and ground water remediation


Weight & Dimensions

Approx Length (Inches)

40" (101.6 cm)

Details

Capacity

As Needed

Cartridge Style

Drop-In

Case Quantity

15

End Cap Type

226 O-Ring with Spear

Filter Application

Sediment/Dirt/Rust

Media Type

Polypropylene

Micron Rating (Absolute)

1 Micron

O Rings

Fluorocarbon

Operating Temperature Range

Max 180 Degrees Fahrenheit

Outer Diameter

2.5"

Warranty & Certifications

Certifications

Tested and certified by WQA according to NSF/ANSI Standard 61 for material requirements only


3M





The Betapure NT-T Series cartridges are designed to provide superior service life while also delivering a consistent filtration efficiency. The filters combine polypropylene media with fluid distribution netting to form multiple layers. This allows for greater fluid movement from layer to layer as it passes through the three distinct media sections.

Specifications:
  • Case of 15 filters
  • End Caps: 226 o-ring with spear
  • O-ring Material: fluorocarbon
  • Filter Dimensions: 40" L x 2-1/2" OD
  • Micron Rating: 1 micron absolute
  • Tested and certified by WQA to NSF/ANSI Standard 61 for material requirements only
Applications:
  • Chemical and hydrocarbon processing - acids, bleach (sodium hypochlorite), polyethylene and polypropylene manufacture, amine sweetening and waterflood
  • Food and beverage applications - bottled water particulate and turbidity reduction, reverse osmosis membrane and spray nozzle protection, diatomaceous earth or carbon fine trap, beverage blending, rinsing and water water
  • Fine chemical and electronics - pre-RO filtration of high silt density index incoming water, copper sulfate plating bath filtration in printed circuit board construction, color screen filtration for CRT production
  • Coating - film and paper coatings, photographic film, lens coatings, can coatings, high quality paints and ink
  • Industrial - machine tool lubrication, chemicals, detergents, waste water, textiles, plating baths, pulp and paper, process water and ground water remediation

Weight & Dimensions

Approx Length (Inches)

40" (101.6 cm)

Details

Capacity

As Needed

Cartridge Style

Drop-In

Case Quantity

15

End Cap Type

226 O-Ring with Spear

Filter Application

Sediment/Dirt/Rust

Media Type

Polypropylene

Micron Rating (Absolute)

1 Micron

O Rings

Fluorocarbon

Operating Temperature Range

Max 180 Degrees Fahrenheit

Outer Diameter

2.5"

Warranty & Certifications

Certifications

Tested and certified by WQA according to NSF/ANSI Standard 61 for material requirements only
