Blue-White F-300 Pitot Tube Acrylic Flowmeter


The Blue-White F-300 Flowmeters are made of one piece machined acrylic bodies and corrosion resistant 316SS or Teflon internal float materials. Dual GPM/LPM scales are printed on both sides of the meter. The F-300 mounts easily to existing horizontal pipe; no unions or adapters required!

  • Maximum Temperature = 190°F at 0 PSI
  • Maximum Pressure = 150 PSI at 70°F
  • Accuracy = +/- 10% (of the full scale reading)
  • Mounts onto horizontal pipe
  • Mounting SS clamps and gasket included
  • Acceptable for outdoor installations (direct sunlight)
  • Pitot (impact) tube design makes it easy to install on existing pipe

Part #Flow RateSize
F-30100P5 - 40 gpm
1" Saddle
F-30150P20 -100 gpm
1.5" Saddle
F-30200P40 - 150 gpm
2" Saddle
F-30600P250 - 1050 gpm"
6" Saddle

The F-300 series flowmeters should only be used on the size and type of pipe for which they were intended. Incorrect use will result in inaccurate readings and leakage problems.

 Blue-White F-300 Technical Data Sheet
Types
Housings Materials
Acrylic
316 Stainless Steel, Teflon
Neoprene
300 Series Stainless Steel
Housing Type
Saddle
Port Sizes
1" Saddle, 1-1/2" Saddle, 2" Saddle, 6" Saddle
Air Ranges
Operating Conditions
14 to 110 °F
+/- 10 %
150 psi
5-1050 gpm
